Product Overview
Hobbywing Ezrun 3652-G2 motor 4000KV sensorless HW30402601
The HobbyWing EzRun 3652 G2 motor features an Innovative 4-pole-8-magnet "staggered pole" rotor (Hobbywing-patented). It has low cogging effect and torque pulsation for improved control feel around corners. The built-in temperature sensor and sensor port protect the motor from damage due to overheating when pairing with an EzRun Max10/Max10 SCT ESC.
HobbyWing EzRun 3652 G2 4000KV SL Motor (1/10th Buggy)
Features:
Innovative 4-pole-8-magnet "staggered pole" rotor
Built-in temperature sensor and sensor port
O-ring seal fitted between the front end bell and motor case
Special design motor case (the end attaches to the front end bell) isolates inner coils from outside to protect winding from being damaged by overlong screws
Special technology for temperature control for less heat and more efficiency (efficiency rate of up to 90%)
CNC machined aluminium housing, high purity copper windings and advanced rotor structure
Rebuild-able design for easy routine maintenance
Spec Check
Scale: 1/10th
Brushed/Brushless: Brushless
Sensored/Sensorless: Sensorless
Pole Count: 4
KV Rating: 4000
LiPo Cells: 2-3S
No-load Current(A): 5.2
Timing: 0 Degrees(Fixed)
O.D.(mm): 36.00
Length (mm): 52.00
Shaft Diameter (mm): 3.175
Weight (g): 216
