Product Overview
Power HD Standard DC Motor Copper and Aluminum Gear Servo PHD-LW-25MG
Specifications
Torque(6.0V) 23.0 kg-cm (319.4 oz/in)
Torque(7.4V) 25.0 kg-cm (347.2 oz/in)
Speed 0.16 sec (6.0V) ~ 0.14 sec (7.4V)
Operating Voltage 6.0 ~ 8.4 DC Volts
Weight 72 g (2.54 oz)/td>
Bearing Type Ball Bearing x 2
Motor Type DC Motor
Gear Type Copper & Aluminum
Operating Temperature -20 ~ 60
Working frequency 1520 s / 333hz
Size 40.7 x 20.5 x 38.6 mm ( 1.60 x 0.81 x 1.52 in)
